铝管
Model:
- Model:
- Product Type: cooler
- Door Type: top open
- Height: below or equal 1.2m/3.9ft
v
Technical Data
- Catalog - Small Display Coolers (Countertop & Slim)
- Catalog - Small Display Freezers (Countertop & Slim)
- Catalog - Supermarket Merchandisers Freezers & Deli Counters
- Catalog - Ice Cream Dipping Cabinets
- Catalog - Refrigerated Cases for Cakes, Pastry and Bakery
- Catalog - Stainless Steel Kitchen Refrigerators
- Catalog - Upright Commercial Freezers (Freestanding)
- Catalog - Upright Commercial Coolers (Freestanding)
- Catalog - Commercial Chest Freezers
- Catalog - Electric Barrel Can Cooler
Product Details
Tube Size | OD(MM) | Wall Thickness(mm) | Material |
Φ4.76 | 0.8 | ||
Φ6.0 | 0.7,0.75,1.0 | ||
Φ6.35 | 0.5,0.6,0.75,0.8,1.0 | ||
Φ6.5 | 0.75 | ||
Φ7.0 | 0.7,0.75,0.8,1.0 | ||
Φ7.5 | 0.7,0.75 | ||
Φ8.0 | 0.5,0.65,0.7,0.8,0.9,1.0 | ||
Φ12.0 | 1.0,1.2 | ||
Φ12.7 | 0.65,0.8,1.0,1.15,1.2 |
Tensile strength(Mpa) | Elongation (%) |
60-90 | ≥30 |
Temper | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | other | Al |
1060 | 0.20 | 0.25 | 0.03 | 0.03 | 0.03 | --- | 0.03 | 0.03 | 0.03 | Remain |
1050 | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | --- | 0.05 | 0.03 | 0.03 | Remain |
1070 | 0.2 | 0.25 | 0.04 | 0.03 | --- | --- | 0.04 | --- | 0.03 | Remain |
1100 | 0.95 | 0.05-0.2 | 0.05 | --- | --- | --- | 0.1 | 0.03 | Remain | |
3003 | 0.60 | 0.70 | 0.05-0.20 | 1.0-1.5 | --- | --- | 0.1 | --- | 0.15 | Remain |
3102 | 0.60 | 0.70 | 0.30 | 0.3-0.8 | 0.2-0.8 | 0.2 | 0.4 | --- | 0.15 | Remain |
-
